| Place of Origin: | China |
| Brand Name: | CAMEL |
| Certification: | CE RoHS |
| Model Number: | 808W |
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | reasonable prices |
| Packaging Details: | paperbox for each unit; carton box for 100pcs at dimension 51*43*33cm |
| Delivery Time: | within 5 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 40,000pcs per month |
| Dimension: | 86*86*55mm | Color: | Green |
|---|---|---|---|
| Output: | 2NO/2NC/2COM | Current: | 3A@36V DC Max. |
| Feature: | Resettable | Graphics: | International Graphics |
| Weight: | 0.2kg | Package: | 100pcs/20kg/51*43*33cm/ctn |
White Color Call Point Resettable Manual Emergency Call Point
Keywords
Call Point; resettable call point, fire alarm call point; emergency button, breakglass button, fire alarm button,press to break glass button;
Features
1, glass appearance maintains deterrence
2, resettable, no need to open to reset - just use the key provided
3, complete functional test with every activation
4, two built-in resistor values minimised installation erroes and ensures compatibility
5, double pole double throw
6, available in green and red colors
7, surface mount
Technical Parameter
| Parameter | Description |
| Size | 86*86*55mm |
| Standard Structure | Fireproof Material, sandblast finished |
| Output Contact | DPDT 2NO/2NC/2COM |
| Lifetime | 100000 Tested |
| Feature | Resettable Emergency Button |
| Working Temperature | 10-55C |
| Working HUmidity | 0-95% (relative humidity) |
